● 22kW AC charger improves parking turnover
● RFID and ISO 15118 authentication for user management
● Low standby power consumption for energy-saving
● Remote management by built-in network connectivity
● OCPP compliance enables backend system integration
● IP55 and wallmount/stand installation provides high adaptability”
● ฟรี!! RFID for user authentication Charging จำนวน 2 ใบ
Charging Cable Length : หัวชาร์จ Type 2 ความยาวสาย 5 เมตร
● Warranty 2 Years
| Model | Delta AC MAX 22kW 3-Phase |
| Power | 400 Vac, 32 A (maximum), 50-60 Hz |
| Wire | L1, L2, L3, N and PE, hardwired with terminal block |
| Standby Power * | < 2.6 W |
| Charging Interface * | 22 kW |
| Charging Interface * | (1) IEC 62196-2 Type 1 or Type 2 tethered plug |
| (2) IEC 62196-2 Type 2 Socket | |
| (3) IEC 62196-2 Type 2 Socket with shutter |
| Internal RCD | AC 30 mA, DC 6 mA |
| Electrical Protection | Over current, Under voltage, Over voltage |
| Over temperature,Surge protection, | |
| Short circuit, Ground fault | |
| Upstream Breaker | In accordance with local regulations |
| Cold-Load Pickup | Randomized delay before charge resume after power failure |
| Automatic Recovery | Automatically resume charging after a minor fault |
| No user intervention required |
| Operating Temperature | -30 ºC to +50 ºC (-22 ºF to +122 ºF) |
| Storage Temperature | -40 ºC to +80 ºC (-40 ºF to +176 ºF) |
| Humidity | < 95% relative humidity, non-condensing |
| Altitude | Up to 2,000m (6,500ft) |
| Ingress Protection | IP55 |
| Enclosure Protection | IK09 according to IEC 62262 |
| Cooling | Natural cooling |
| Charging Cable Length | 5m |
| Dimension (W x H x D) | 218 x 371 x 167 mm ( 8.6 x 14.6 x 6.6 inch)excluding charging cable, mounting plate and cable holder |
| Weight ** | 3.8 kg (8.3 lbs), without package |
